MODEL

8KW

Waveform of the input voltage

Sine (utility or generator)

Rated input voltage

230Vac

Low loss Voltage

170Vac ± 7V ( UPS )

90Vac± 7V ( Appliances )

Low loss Return voltage

180Vac ± 7V ( UPS ) ;

100Vac ± 7V ( Appliances )

High loss Voltage

280Vac ± 7V

High loss Return voltage

270Vac ± 7V

Maximum AC input voltage

300Vac

Maximum AC input current

60A

Maximum 2nd output current

40A

Rated input frequency

50Hz / 60Hz (auto detect)

Low loss rate

40±1Hz

Low loss Return frequency

42±1Hz

High loss rate

65±1Hz

High loss Return frequency

63±1Hz

Output short circuit protection

Line mode: automatic switch

Battery mode: electronic circuits

Efficiency (line mode)

>95% (nominal R load, fully charged battery)

Transfer time

10ms typical (UPS);

20ms typical (household appliances)

Output power derating:

When the AC input voltage is lower than 170V for the 8kW model, the output power will be reduced.

MODEL

8KW

Rated output power

8000W

Waveform of the output voltage

Pure sine wave

Output voltage regulation

230Vac ± 5 %

Output frequency

60Hz or 50Hz

Maximum efficiency

93%

Overload protection _

100ms@≥205% load ; 5s@≥150% load ; 10s@110%~150% load

Peak capacity

Nominal power 2* for 5 seconds

Warning DC low voltage

@ load < 20%

46.0 Vdc

@ 20% ≤ load < 50%

42.8 Vdc

@ load ≥ 50%

40.4 Vdc

Low DC Warning Return Voltage

@ load < 20%

48.0 Vdc

@ 20% ≤ load < 50%

44.8 Vdc

@ load ≥ 50%

42.4 Vdc

Low DC cut-off voltage

@ load < 20%

44.0 Vdc

@ 20% ≤ load < 50%

40.8 Vdc

@ load ≥ 50%

38.4 Vdc

High RE Recovery voltage

64Vdc

High DC cutoff voltage

6 6 Vdc

DC voltage accuracy

+/-0.3V@ without load

THD extension

<5% for linear load, <10% for non-linear load at rated voltage

DC Offset

≦ 100mV

No load energy consumption

<85W

Power limitation

When the battery voltage is lower than 50Vdc, the output power will be reduced. If the connected load is greater than this reduced power, the AC output voltage will decrease until the output power reduces to this reduced power. The minimum AC output voltage is the output voltage setting – 1 0V.

Utility charging mode

MODEL

8KW

Charging current (UPS)

@ Rated input voltage

12 0A (@V _I/P =230Vac)

Bulk charge voltage

Battery flooded

58.4 Vdc

AGM/Gel battery

56.4 Vdc

Fluctuating charge voltage

54Vdc

Overload protection

66Vdc

Charging algorithm

3 -Step

charge curve

Solar entrance

MODEL

8KW

Nominal power

8000W _

Maximum. Open circuit voltage of the photovoltaic field

500Vdc

PV array MPPT voltage range

90Vdc~450Vdc

Maximum. Input current

18Ax2

Starting voltage

80V +/- 5Vdc

Power limitation
